Model Name |
AMG-08OPHA02N1 |
Screen Size |
8.4" |
Active Display Area (mm) |
170.4(H) x127.8(V) |
Pixel Pitch (mm) |
0.213(H) x 0.213 (V) |
Display Mode |
Normally white |
Display Resolution (pixel) |
800x600 |
Contrast Ratio |
500:1 |
Display Color |
262K colors |
Brightness (CD/㎡) |
200 |
Backlight |
LED |
Viewing Angles (CR =10) |
130(H); 110 (V) |
Response Time(Typ.Tr+Tf) |
35ms |
Signal Connector |
VGA/DVI |
Power Consumption |
DC 12V |
Dimension(VxHxT) |
210x149x25 |
Operating Temperature |
0~50℃ |
Storage Temperature |
-20~60℃ |
Relative Humidity |
5(%RH)~90(%RH) |
