Model Name |
AMG-15PPC01NC |
|
CPU |
Intel ATOM N2600 Dual core 1.6GHz |
|
Memory |
RAM 2GB.DDR3 SO-DIMM |
|
HDD |
HDD 320 G 5400 RPM.2.5 SATA |
|
HDMI port |
1xHDMI port |
|
COM ports |
Default x 4 COM |
|
USB 2.0 ports |
Default x 3 USB 2.0 |
|
Ethernet ports |
1x10/100/1000base-T Gigabit Ethernet |
|
Audio |
Line-out,mic-in |
|
Display Size(Diagonal) |
15" |
|
Active Display Area(mm) |
304.128(H)x228.096(V) |
|
Max Resolution |
1024x768 |
|
Support Color |
16.2M |
|
Luminance(CD/M ) |
250 |
|
Contrast Ratio |
700:1 |
|
Pixel Pitch(mm) |
0.297(H)x0.297(V) |
|
Viewing Angle |
160(H);140(V) |
|
Response Time(Typ.Tr+Tf) |
8ms |
|
Backlight |
LED |
|
Type |
NA |
|
Use connector |
NA |
|
Input Voltage |
AC 90-264V 4A 47～63Hz |
|
Output Rating |
60W(max) |
|
Output Voltage |
DC12V@2.5A; |
|
Dimension(VxHxT) |
410.4x317.4x83 |
|
Operating Temperature |
-30～85℃ |
|
Storage Temperature |
-30～85℃ |
|
Relative Humidity |
5[%RH]～90[%RH] |
