Model Name |
AMG-19PPC02T5 |
|
CPU |
Intel ® Bay Trail J1900 Mini-ITX(2GHz) |
|
Memory |
DDR3L 1333/1600MHz 2GB |
|
HDD |
60GB (optional) |
|
COM ports |
1 x COM port |
|
PS/2 port |
NA |
|
VGA port |
1 x VGA port |
|
HDMI port |
1 x HDMI port |
|
USB ports |
Default 2 x USB 2.0 |
|
Ethernet ports |
1x10/100/1000BASE-T Gigabit Ethernet |
|
Audio |
Line-out,Mic-in |
|
Display Size(Diagonal) |
19" |
|
Active Display Area(mm) |
376.32(H)x301.06(V) |
|
Max Resolution |
1280x1024 |
|
Support Color |
16.7M |
|
Brightness(CD/㎡) |
250 |
|
Contrast Ratio |
1000:1 |
|
Pixel Pitch(mm) |
0.264(H)x0.264(V) |
|
Viewing Angle |
170(H);160(V) |
|
Response Time(Typ.Tr+Tf) |
5ms |
|
Backlight |
LED |
|
Type |
Resistive Touchscreen |
|
Use connector |
4pin USB2.0 |
|
Input Voltage |
AC 90-264V 4A 47～63Hz |
|
Output Rating |
60W(max) |
|
Ouput Voltage |
+12V @5A; |
|
Dimension(VxHxT) |
474.6x399.6x90.36 |
|
Operating Temperature |
0～50℃ |
|
Storage Temperature |
-20～60℃ |
|
Relative Humidity |
5[%RH]～90[%RH] |
